Bixolon SRP-275III dot-matrix receipt printer

Overview

SRP-275III 3” serial dot matrix receipt printer suited to a range of applications, from kitchen printing, to end-of-day reporting, customer receipting, service reports and can produce simultaneous multiple copies. All of this makes the SRP-275III dot matrix printer suitable to a variety of environments. Part of the Bixolon SRP Series Drivers and utilities can be found here, see more about the Bixolon SRP-275III in it's YouTube Showcase.

Download Product Specification

Register to get started

Apply for a ForPOS account to view pricing, receive exclusive discounts and some other incentive etc etc.

My account

Key Features

  • High performance dot matrix printer
  • Two colour printing
  • Ergonomic design for counter space saving
  • Internal kitchen buzzer and built in SMPS
  • Simple drop-in paper loading
  • Stand-alone and wall-mount options
  • Energy Star Compliant
  • 2 year warranty

Featuring an ergonomic easy clean design and easy print paper loading, the SRP-275III has the option of either Tear-Bar or Auto-cutter. Boasting three interface options including USB V2.0 FS + Serial + Ethernet*, USB V2.0 FS + Parallel or USB V2.0 FS + Serial (*DHCP enabled).

Offering Intelligent Logic Seeking and Bi-Directional Print Technology, the SRP-275III is fast and quiet and has the ability to print multiple copies with reliability of up to 18 million lines. Alongside a Virtual Memory Switch Manager (VMSM) allowing the printer settings and the default language to be changed easily. The SRP-275III also features an easy logo/firmware download program to efficiently update receipt designs with company logos.

Specification
Print Method Dot Matrix
Print Speed 5.1 lps (at 40 columns)
Print Resolution 80 dpi (Horizontal) 144 dpi (Vertical)
Print Width Up to 63.5 mm
Sensor Paper End, Paper Near End, Wall Mounting Paper Near End, Rear Cover Open, Black Mark
Media Type Receipt
Media Width 76.5 mm
Media Roll Diameter Up to 83 mm
Media Thickness 0.06 ~ 0.085 mm
Supply Method Easy Paper Loading
Dimensions (WxLxD) 160 x 239 x 157 mm (6.29 x 9.40 x 6.18 inch)
Weight A: 2.4 kg (5.29 lbs.) C: 2.5 kg (5.51 lbs.)
Power EnergyStar Certified, External Power Adaptor 100-240V AV, 50/60Hz
Drawer Port 2 ports (via y-type adapter)
Memory 64 Mbit SDRAM, 16 Mbit FlashROM
NV Image Memory 256 Kbytes (mono)
Receive Buffer 64 Kbytes
User Define Buffer 64 Kbytes
Interface Triple Interface USB V2.0 FS + Serial + Ethernet
Temperature Operating: 0 ~ 40℃ (32 ~ 104℉) Storage: -20 ~ 60℃ (-4 ~ 140℉)
Humidity Operating: 10 ~ 80% RH Storage: 10 ~ 90% RH
Thermal Print Head (TPH) 300 Million Dots/Wire
Auto Cutter 1.5 Million Cuts
Emulation BXL / POS
Driver / Utility Windows Driver, OPOS Driver, JPOS Driver, Linux / Mac CUPS Driver, Virtual COM USB/Ethernet Driver, Utility Program
SDK iOS SDK, Android SDK
Character Size Font A: 9 x 9 Font B: 7 x 9 KOR: 17 x 9 CHN: 16 x 16
Characters Per Line Font A: 35 Font B: 40 KOR: 20 CHN: 22
Character Sets Alphanumeric: 95 Extended Graphics:128 × 27 page International: 48
Graphics Supporting user-defined fonts, graphics, formats, and logos
Optional Wall Mount, Splash Proof Cover, Ribbon Catrridge, B-Melodist, External Buzzer
