Posiflex TM-3114E 14" LCD Touch Montior


Posiflex  TM-3114E standalone touch monitor is a perfect companion that can connect to an existing POS system. Built with the same standards as Posiflex’s POS terminals, the standalone monitors come in two versions: the TM Series, which has a touchscreen; and the LM Series, which has a non-touch display. They can be wall-mounted to improve countertop space, keeping customer-facing areas free from clutter.

Register to get started

Apply for a ForPOS account to view pricing, receive exclusive discounts and some other incentive etc etc.

My account

Key Features

  • 14" TFT LCD
  • Bezel-free PCAP touch
  • Interface - USB

The TM-3114E comes with a 14″ wide screen bezel-free PCAP touch panel offers flexibility via simple integration of side mounted accessories such as MSR (SL-104). It can be wall mounted to improve counter top space and keep customer facing areas tidy and free from clutter.

Resolution Up to 1366 x 768
Active Area 309.399 (H) x 173.952 (V)
Pixel Pitch 0.2265 (H) x 0.2265 (V)
Pixel Arrangement RGB Vertical Stripe
Viewing Angle 20/45/45/45 degree (U/D/L/R)
Contrast Ratio 600 : 1
Response Time 3 ms (Raising)/7 ms (Falling)
Brightness 220 cd/m2
Touch Type Bezel-free PCAP touch
Interface USB
Display Interface VGA
Power Supply 12V/18W
Dimension (W x D x H in mm) 372 x 252 x 271
Weight (N.W. in kg) 3.69
Operating Condition Temp: 0~50゚ Humidity : 20%~85%RH
VESA Mounting Support Yes Options
Options MSR Side Attachment
