Phoenix Pro Fan-Free EPOS Terminal

Overview

The Phoenix Pro is a fan-free, reliable, energy-saving epos terminal. Designed with a sleek base and magnetic cable cover for a professional and modern look. Furthermore, the Phoenix Pro epos terminal comes with a 15" true-flat projected capacitive touch screen. With all of these features combined the Phoenix Pro makes the ideal epos terminal for numerous industries. The Phoenix Pro also makes for a good starting point when ordering one of our epos bundles. See more about the Phoenix Pro in our Youtube Showcase

Download Product Specification

Register to get started

Apply for a ForPOS account to view pricing, receive exclusive discounts and some other incentive etc etc.

My account

Key Features

15" Industrial-grade LCD with multi-point touch panel
Intel Elkhart Lake J6412(10nm), i3/i5 optional
DDR4 RAM and SATA 2.5” SSD
Customized fan-free motherboard for POS application

The Phoenix Pro has a variety of features to increase usability and efficiency:

15″ Industrial-grade LCD with multi-point touch panel;
Intel Elkhart Lake J6412(10nm), i3/i5 optional
Customized fan-free motherboard for POS application, stable and energy-saving;
DDR4 RAM and SATA 2.5” SSD;
Aluminum Die-casting housing, splashproof and dust-prevent;
Sleek base with an innovative magnetic cable cover, Logo light optional;
Standard I/O ports and VESA mount supported
Modular-design: 2nd Display, MSR, I Button, VFD, Scanner
Optional for VGA setting via BIOS (J6412 MB)

Specifications
CPU Support	Intel Elkhart Lake J6412 2.0GHz (up to 2.6GHz,1.5MB Cache); Intel Core i3-6100U 2.3GHz 3MB Cache; Intel Core i5-6200U 2.3GHz (up to 2.8GHz,3MB Cache)
System Memory	1 x DDR4,SO-DIMM , 4GB (Max. 32GB); 1 x DDR4, SO-DIMM, 4GB (Max. 16GB); )1 x DDR4, SO-DIMM, 4GB (Max. 16GB)

Storage
SATA	1x 2.5” SATA SSD 128GB (64G/256G optional )
mSATA	1x mSATA-SSD(Optional)

LCD
Size	15" TFT LCD Panel
Brightness	350cd/m2 (Typ.)
Resolution	1024 x 768

Touch Screen	True-Flat Projected Capacitive Touch
Tilt Angle	0 ~ 60 degre

External I/O Port
USB	4 x USB 3.0 +2 x USB 2.0 Powerd,default setting
Serial Port	3 x Serial port (RJ50); (COM1~3: 0/5/12V by pin-JP)
VGA	1 x VGA (Power enable by BIOS; +12V)
Cash Drawer Port	1 x RJ11,12V(Controls 2drawers Dual Independent Sensor)
LAN	1 x LAN (10/100/1000Mb)
Audio	1 x Mic-In/Speaker-out (Combo Jack)
DC-IN	1 x DC In(4PIN)
Power Switch	1 x Power Switch

Speaker	2 x 2W speaker (Optional)
Base LED	USB,White,95X20X2.8mm (Optional)
Power	External power adapter, 12V-5A/60W
EMC Safety	CE, ROHS

Environment
Operating Temperature	0°C ~ 35°C
Storage Temperature	-15°C ~ 60°C
Operating Humidity	20% - 85% RH non condensing
Storage Humidity	20% - 85% RH non condensing
