Posiflex HS-6714W All In One POS

Overview

HS-6714W

  • 14" True Flat PCAP Multi Touch Display
  • Powered by Intel's Whiskey Lake Core Processors
  • Support MSR, Fingerprint Sensor, RFID Reader, Barcode Scanner and Thermal Printer
  • Modular Design with Detachable Printer
  • Quick Access to I/Os

Download Product Specification

Register to get started

Apply for a ForPOS account to view pricing, receive exclusive discounts and some other incentive etc etc.

My account

Key Features

  • 14" True Flat PCAP Multi Touch Display
  • Intel Whisky Lake Core i3-8145UE, up to 3.90 GHz, 4.0M Cache / Intel Whisky Lake Core i5-8365UE, up to 4.10 GHz, 6.0M Cache
  • DDR4 SO-DIMM x 2, max. 64GB
  • M.2 connector x 2 (support SATA signal only)

Small Form Factor

Its compact footprint takes space saving to extremes and creates a clean, cable-free environment.

Award-winning All-in-one Solution

The HS-6714W integrates the most widely used peripherals options in daily POS operation including MSR, fingerprint sensor, RFID reader, barcode scanner and thermal printer.

Modular Design

Detachable modularized printer design allows quick access to the components, enabling convenient, efficient serviceability.

System-Configuration
Processor Intel Whisky Lake Core i3-8145UE, up to 3.90 GHz, 4.0M Cache / Intel Whisky Lake Core i5-8365UE, up to 4.10 GHz, 6.0M Cache
System Memory DDR4 SO-DIMM x 2, max. 64GB
Storage Device M.2 connector x 2 (support SATA signal only)
TPM TPM 2.0
Power Supply 24V/100W
OS Support Windows 10 IoT LTSC / Windows 11 IoT LTSC
Display & Touch
LCD 14" TFT LCD
Resolution 1366 x 768
Touch True-flat PCAP touch with multi-touch support (IP65 on front panel)
I/O Expansion
Serial Port DB9 x 2 + RJ50 x 1, 5V/12V support on all COM ports
Parallel Port Yes
Standard USB Port USB 3.0 x 4
OTG USB N/A
LAN Port 10/100/1000 Mb x 1
Display Port VGA x 1 (12V support for Posiflex monitors )
CR Port RJ11 x 1, control 2 CR via optional Y-cable (printer driven), supporting 24V cash drawer
PS2 Port Yes
Audio Line-out / Mic-in combo jack x 1
Expansion Slot M.2 slot x 1
Dimension
Dimension (W x D x H in mm) 371 x 210 x 476
Weight (N. W. in kg) 5.8
Environmental
Operating Condition 0°C - 40°C, 20%RH - 90%RH
Storage Condition -20°C - 70°C, 10%RH - 90%RH
Built-In Options
WiFi module M.2 WiFi/BT module
Printer Module PP-7900, 3" speedy thermal printer, 250 mm/sec (max.)
MSR Module 3 tracks ISO or JISII (HID/VCOM selection)
Scanner Module 2D barcode scanner
RFID Reader Module Support MIFARE Ultralight and Classic 1K card (HID/VCOM Selectable)
iButton Module Yes (cannot coexist with Fingerprint Sensor)
4G/LTE Communication Module Single SIM slot, selected band support
Fingerprint Sensor Module Optical type
Attachment Options
POS Monitor Non-touch TFT LCD: 7"/9.7"/12.1"; PCAP touch TFT LCD: 9.7"
Line Display 2 x 20 rear-mount VFD customer line display; 2 x 20 rear-mount LCD customer line display;
*product specifications and model configurations are subject to change and may vary by global region.
